2xAmpere? Altra? LGA4926 Pins CPUs,80 Arm v8.2+64-bit CPU cores at 3.3 GHz with Sustained Turbo; Up to 250W

Memory

32x DDR4 DIMM Slots,  Up to 3200MT/s

Integrated Network

1x 1GbE dedicate IPMI Port

Storage

Front: 12xLFF SAS/SATA/NVMe  or 24xSFF NVMe(*開發中)

Rear: 4x SFF SAS/SATA/Nvme

Rear PCIe Extension

Max  8x PCIe Card + 1x OCP 3.0

• Riser 1: FHFLx16 + FHFLx16 + FHHLx8

• Riser 2: FHFLx16 + FHFLx16 + FHHLx8

• Riser 3: FHFLx8 + FHFLx8 (Optional )

• SFF OCP3.0(Multihost)

External IO

2x Front & 2x Rear USB 3.0, Type-A

1x PWR BTN with LED

1x Front UID BTN with LED + 1x Rear UID LED

1x Front VGA +1x Rear VGA

1x Rear COM port(DB9)

System MGNT

IPMI 2.0 management, ASPEED AST2500 BMC

Security

TPM header for TPM2.0/TCM2.0

PSU

1+1 Redundant 185mm CRPS

800W/1600W/2000W

90 V~264 V AC or 200 V ~ 300 V DC

System  Fans

4x 8038

Temperature

5~35℃

Dimension

87mm (H) x 436mm (W) x 815mm (D)
